회전식 펄버라이저

Specification		JFRP18C	JFRP20	JFRP20C
Max Opening Width	mm	660	850	800
Weight	kg	1800	2400	2500
Shear Force (average)	kN	1460	2700	2700
Crushing Force (end)	kN	520	800	800
Working Pressure (Cylinder)	kg/cm²	300-350	300-350	300-350
Oil Flow (Cylinder)	L/min	140-240	180-240	180-240
Working Pressure (Motor)	kg/cm²	120-160	120-160	120-160
Oil Flow (Motor)	L/min	30-50	30-50	30-50
Suitable Carrier	ton	15-20	20-30	20-30
Teeth	-	Single Tooth	Fixed and cannot be replaced	Whole Jaw Plate Replaceable
Rotation Mode	-	Hydraulic Rotation, 360° Free Rotation

Dimensions		JFRP18C	JFRP20	JFRP20C
A (Total Length)	mm	1850	1980	1980
B (Max Opening Width)	mm	660	850	800
C (Cutter Length)	mm	140	200	200
D (Overall Width)	mm	662	662	662
E (Jaw Depth)	mm	585	645	670
